Selecting Magnetic Tools




The holding power of magnet varies substantially as per the conditions.

Maximum Holding Power

Maximum holding power is found by contacting entire work face of the magnet on a fixed ideal load without air gap and pulling up vertically until the magnet tears loose.

Ideal Load
Material :SS400 or equivalent
Contact Surface :∇∇∇
Thickness :Thick enough

Lifting Conditions

①Material of the Load
②Thickness of the Load
③Air Gap between the Magnet and the Load
④Contact Area of the Magnet



TThe holding power varies as per the material, thickness of the load, conditions of the contact surface and air gap between a magnet and the load.


① Effect of Thickness on Holding Power
※The holding power decreases as the plate become 板厚

As the size of magnet becomes smaller and/or pole pitch becomes smaller, comparatively the holding power to the thinner load increases.

② Effect of Air Gap on Holding Power
※The holding power decreases as the air gap between a magnet and a load become larger.


③ Effect of Material on Holding Powerbr /> ※ The holding power on SS400 is defined as standard.


④ Effect of Surface Roughness on Holding Power
